10 x Huawei IR Quattro HD Presence Sensor Security Appliance - Open box

The IR Quattro HD is a high-precision indoor presence detector equipped with passive infrared (PIR) technology, designed for ceiling installation in commercial, industrial, or public spaces. With 13 detection levels and 4,800 switching zones, it ensures accurate presence detection and efficient lighting control across wide areas.

This unit supports master/slave and master/master configurations and offers flexible brightness response settings, making it ideal for smart building automation, energy savings, and lighting control. The Open Box unit is unused and fully functional, with minor signs of packaging handling.

✔ Key Features & Benefits

✔ High-Density PIR Sensor with 4,800 switching zones and 13 detection levels for precise motion detection
✔ Large Detection Coverage – up to 400 m² tangential, 64 m² presence zone, and adjustable reach
✔ Ceiling-Mount Design with adjustable installation height from 2.5 to 10 meters
✔ Flexible Configuration – supports master/master or master/slave setups for scalable installations
✔ Teach-In Function with optional remote control (RC8) for quick and user-friendly setup
✔ IP54 Protection with AP Box for added durability in varied environments
✔ Customizable Brightness Response from 10–1000 lx or daylight mode

✔ Ideal Uses

✔ Office lighting automation with energy-saving PIR detection
✔ Conference rooms, classrooms, or open-plan spaces requiring zoned presence sensing
✔ Commercial buildings seeking reliable motion-based control solutions
✔ Integration into smart building systems with remote control capabilities

✔ Specifications

✔ Condition: Open Box – Device is unused and in excellent condition. Packaging may show signs of handling. Fully tested and 100% functional.
✔ Type: Presence Detector
✔ Sensor Type: Passive Infrared (PIR)
✔ Installation: Ceiling Mount (Indoor Use)
✔ Dimensions:
 • Standard: 120 × 120 × 70 mm
 • Surface-Mount (AP): 120 × 120 × 65 mm
✔ Detection Zones:
 • Presence: 8 × 8 m (64 m² max)
 • Radial: 8 × 8 m
 • Tangential: 20 × 20 m (400 m² max)
✔ Recommended Install Height: 2.5 to 10 meters
✔ Sensor System: 13 Levels / 4,800 Zones
✔ Adjustable Reach: Yes (Mechanical)
✔ Configurations: Master/Master, Master/Slave
✔ Response Brightness: 10–1000 lx, ∞ / daylight
✔ Response Brightness (DIM version): 100–1000 lx, ∞ / daylight
✔ IP Rating:
 • Standard: IP20
 • With AP Box: IP54
✔ Protection Class: II
✔ Operating Temp Range: -25°C to +55°C
✔ Enclosure: UV-resistant, paintable
✔ Accessories (Sold Separately):
 • RC5 User Remote – EAN: 4007841 592806
 • RC8 Service Remote – EAN: 4007841 559410
 • Surface-Mount Adapter (AP Box) – EAN: 4007841 000363
 • Guard Cage – EAN: 4007841 003036
✔ Warranty: 3 Month Carry-in Warranty
✔ What’s in the Box: 10 x IR Quattro HD Presence Detector Only
