Dell PowerSwitch S3048-ON 48x1GbE RJ45 4x10GbE SFP+ F2R XPRV5 - Refurb

Refurbished Dell Switch – This second-hand Dell PowerSwitch S3048-ON is a high-performance 1RU top-of-rack switch offering 48 line-rate 1GbE RJ45 ports and 4 SFP+ uplinks for 10GbE connectivity. Designed for enterprise and data center deployments, it supports Layer 2 and Layer 3 switching with full support for IPv4/IPv6 routing, VRF-lite, LAG, and MSTP, with advanced energy-efficient Ethernet features and high-density stacking. The switch comes with 1 x AC PSU, 3 hot-swappable fans, and airflow direction F2R (front to rear).

✔ Key Features & Benefits

✔ 48 x 1000BASE-T RJ45 ports + 4 x 10GbE SFP+ uplink ports
✔ 260Gbps switching fabric, 131 Mpps forwarding rate
✔ Supports advanced Layer 3 routing (OSPF, BGP, VRF-lite)
✔ 1 x hot-swappable AC power supply, 3 x redundant fans (F2R airflow)
✔ Compact 1U rackmount design with low power consumption (87W max)

✔ Ideal Uses

✔ Enterprise network access or aggregation layer
✔ Top-of-rack switch in server rooms or colocation centers
✔ High-performance 1G switching with 10G uplinks
✔ IPv6-capable Layer 3 core or edge deployments

✔ Specifications

✔ Condition: Refurbished device with scratches and scuffs. Device has been extensively tested and is fully functional.
✔ Manufacturer & Model: Dell PowerSwitch S3048-ON
✔ Dell Part Number: XPRV5
✔ Switch Type: Layer 2/Layer 3 Managed Ethernet Switch
✔ Form Factor: 1U Rackmount

✔ Ports:
✔ 48 x 1GbE RJ45 ports (10/100/1000BASE-T)
✔ 4 x 10GbE SFP+ uplink ports
✔ 1 x RJ45 Console Port (RS232)

✔ Performance:
✔ Switching Fabric: 260 Gbps full duplex
✔ Forwarding Rate: 131 Mpps
✔ Packet Buffer: 4MB
✔ MAC Addresses: Up to 80K
✔ IPv4 Routes: Up to 16K | IPv6 Routes: 8K
✔ Host Tables: 40K (IPv4) / 8K (IPv6)
✔ VLANs: 4,000
✔ MSTP Instances: 64
✔ Jumbo Frame Support: MTU up to 12,000 bytes
✔ Latency: ~3.7μs (1GbE), ~1.8μs (10GbE)

✔ Stackability & Redundancy:
✔ Stack up to 6 units
✔ Hot-swappable redundant PSU & fan support
✔ Airflow: Front-to-rear (F2R)

✔ Management & Protocols:
✔ CLI, Telnet, SSHv2, SNMPv1/v2c/v3
✔ Support for IPv4/IPv6 management
✔ VRF-lite, LACP, OSPFv2/v3, BGPv4/v6, RIP, IS-IS
✔ IGMPv1/v2/v3, MSDP, PIM-SM
✔ QoS: 8 queues per port, WRR scheduling
✔ Energy Efficient Ethernet (IEEE 802.3az)

✔ Operating Specs:
✔ Power: 90–264 VAC, 50/60Hz
✔ Max Power Consumption: 87W
✔ Typical Power: 65W
✔ Thermal Output: 290 BTU/h
✔ Operating Temp: 0°C to 45°C
✔ Storage Temp: –40°C to 70°C
✔ Operating Humidity: 5–85% (non-condensing)
✔ Dimensions: 1.71” x 17.09” x 12.6” (4.4 x 43.4 x 32.0 cm)
✔ Weight: 5.84 kg (with 1 PSU)

✔ Standards & Protocols:
✔ IEEE 802.1Q, 802.3ab, 802.3ae, 802.3ad (LACP), 802.3x, 802.1s, 802.1w, 802.1D, 802.1X
✔ RFC support for IPv4/IPv6, BGP, OSPF, VRRP, and more (see full list upon request)

✔ Warranty:
✔ 3-Month Carry-In Warranty

✔ What’s in the Box?
✔ Dell S3048-ON Switch (XPRV5)
✔ 1 x AC Power Supply (F2R airflow)
✔ Power Cable
