Enhance your surveillance capabilities with this used Dahua NVR5216-8P-EI 16 Channel 2HDD 1U Network Video Recorder. Designed for high-performance video recording, this NVR supports up to 16 IP camera inputs and offers advanced AI features such as face detection, face recognition, perimeter protection, and Smart Motion Detection Plus (SMD Plus). With support for up to two hard drives and a compact 1U rack-mountable design, it is ideal for various security applications. The embedded Linux operating system ensures reliability and stability, while the built-in PoE ports simplify camera connections. The NVR is compatible with a wide range of third-party cameras thanks to its ONVIF compliance.

Key Features

16 Channel IP Camera Input: Supports up to 16 IP cameras for extensive surveillance coverage.
Advanced AI Functions: Includes face detection, face recognition, perimeter protection, SMD Plus, and video metadata analysis.
Embedded PoE Ports: 8 PoE ports with support for ePoE simplify camera installation and reduce cabling requirements.
Dual HDD Support: Accommodates up to two SATA hard drives, each supporting up to 20 TB capacity.
High Decoding Capability: Supports up to 4K resolution decoding for high-definition video playback.
Smart H.265+/H.264+ Compression: Efficient video compression reduces storage requirements without compromising quality.
Multiple Video Outputs: HDMI and VGA outputs support simultaneous video streams with heterogeneous video source output.
ONVIF Compatibility: Ensures interoperability with a wide range of IP cameras from different manufacturers.
User-Friendly Interface: Accessible via web and local GUI for easy setup and operation.
Mobile Access: Remote monitoring available through iOS and Android devices.

Ideal Uses

Commercial Security: Suitable for retail stores, offices, and small businesses requiring reliable surveillance.
Residential Surveillance: Ideal for homeowners seeking advanced security features.
Educational Institutions: Enhances campus security for schools and universities.
Industrial Applications: Monitors warehouses and industrial sites for safety and security.
Public Facilities: Perfect for monitoring parks, community centers, and public spaces.

Specifications

Condition: Used device with minor scratches and scuffs. Device has been extensively tested and is 100% functional.
Manufacturer: Dahua
Model: NVR5216-8P-EI
Form Factor: 1U Rack-mounted Network Video Recorder

System

Main Processor: Industrial-grade processor
Operating System: Embedded Linux
Operating Interface: Web, Local GUI

AI Functions

AI by Recorder: Face detection, face recognition, perimeter protection, SMD Plus
AI by Camera: Face detection, face recognition, video metadata (human, motor vehicles, non-motor vehicles), perimeter protection, SMD Plus, stereo analysis, crowd distribution, people counting, ANPR, vehicle density, heat map
AcuPick AI: Max. 16-channel, 1 combined event per channel/s

Perimeter Protection

AI by Recorder: 4 channels, 10 IVS rules per channel
AI by Camera: All channels (16 targets/s)

Face Detection and Recognition

Face Attributes: Gender, age group, glasses, expressions, face mask, beard
Face Database Capacity: Up to 20 face databases with 20,000 images (total capacity 2.5 GB)
Face Recognition Performance:
- AI by Recorder: Up to 2 channels, 12 face images/s each channel
- AI by Camera: 16 channels

Smart Motion Detection Plus (SMD Plus)

SMD Plus by Recorder: 8 channels
SMD Plus by Camera: All channels (32 targets/s)

Video and Audio

Access Channels: 16 channels
Network Bandwidth:
- AI disabled: 384 Mbps incoming, recording, and outgoing
- AI enabled: 200 Mbps incoming, recording, and outgoing
Resolution Support: Up to 32 MP
Decoding Capability:
- AI disabled: Up to 8-channel 8 MP@30 fps
- AI enabled: Up to 6-channel 8 MP@30 fps
Video Output:
- HDMI Port: Up to 3840 × 2160 resolution
- VGA Port: Up to 1920 × 1080 resolution
Multi-screen Display: Supports various display layouts (1/4/8/9/16)
Audio Input/Output: 1-channel RCA input, 1-channel RCA output

Storage

Disk Interface: 2 SATA ports, each supporting up to 20 TB HDD
Disk Group: Supported

Network

Network Protocols: HTTP, HTTPS, TCP/IP, IPv4, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, and more
Mobile Phone Access: iOS and Android
Interoperability: ONVIF 23.12 (Profile T/S/G), CGI, SDK
Network Port: 1 × RJ-45 (10/100/1000 Mbps)
PoE Ports: 8 ports (10/100 Mbps, IEEE 802.3 af/at, supports ePoE)

Alarm

Alarm Input: 4 channels
Alarm Output: 2 channels
General Alarm: Motion detection, local alarm, camera external alarm, network alarm, scene changing, PIR alarm, thermal alarm
Anomaly Alarm: Camera offline, storage error, disk full, IP conflict, login lock, fan abnormality, cybersecurity exception
Intelligent Alarm: Face detection, perimeter protection, face recognition, video metadata, SMD Plus, and more
Alarm Linkage: Record, snapshot, local alarm output, IPC external alarm output, access controller, audio, buzzer, log, preset, email

Interfaces

USB Ports: 2 (1 front USB 2.0 port, 1 rear USB 3.0 port)
RS-232 Port: 1
RS-485 Port: 1
HDMI and VGA Ports: 1 each
Audio Ports: 1-channel input, 1-channel output (RCA)

General

Power Supply: 100–240 VAC, 47–63 Hz
Power Consumption:
- NVR: ≤10 W (without HDD)
- PoE: Total output 130 W, maximum 25.5 W per port
Operating Temperature: –10 °C to +55 °C (14 °F to +131 °F)
Operating Humidity: 10%–93% RH (non-condensing)
Dimensions: 375.0 mm × 329.4 mm × 53.0 mm (W × D × H)
Weight:
- Net Weight: 2.57 kg (5.67 lb)
- Gross Weight: 3.80 kg (8.38 lb)
Installation: Rack or desktop
Certifications:
- FCC: 47 CFR FCC Part15, Subpart B, Class A
- CE-EMC: EN 55032, EN 61000 series
- CE-LVD: EN 62368-1:2014

Warranty

3 Month Carry-in Warranty

What's in the Box

Dahua NVR5216-8P-EI Network Video Recorder
Power Cable
